SURFACE MOUNT WATERPROOF - WEATHERPROOF RADIOS

Surface mount radios serve a purpose if you are adding a new stereo to a piece of equipment that has no visible place for your radio. The versions we sell here at FRS are a one piece style with the tuner and power built in. This makes the install easier. Consider where ever you place the head unit all electrical connections will have to come to the unit like power and speakers. With a surface mount style you have the option of placing it where you can see and use it. If you need additional ways to mount check out our HD pedestals.
Check out the NEW REI AW-30 radio. Same footprint as the Jensen JHD910 & JHD 916BT. Fits same bolt pattern and same connector

SURFACE MOUNT WATERPROOF / WEATHERPROOF RADIOS
"SAVE WITH OUR EXCLUSIVE COMBOS"

866.424.0575

REI 750292
AW-20 KIT Weatherproof AM/FM/WB/BT RADIO w/ Speakers And Antenna
$295.00

FEATURES

• 18 FM / 12 AM preset stations
• Ids tagging
• 40 watt X 4 channel
• Rear USB input for MP3/W/MA playback
• Plays Mp3s W/MA file formats
• Rear RCA AUX input jacks
• Bluetooth audio streaming
• Station presets stored during power loss
• iPod waterproof design
• Fits standard tachometer opening
• 12volt DV power
• 1.80" mounting depth
• Includes Radio, 2 speakers,mounting bracket,antenna, see listed parts...
SPECS

RE AW-20 KIT
What makes this a unique radio, has to be first its size. Designed to fit where no other radio can. Full featured waterproof radio for that open or enclosed vehicle. Matched with a set of 3" surface mounted weatherproof speakers. Sold as a complete system with rubber duckie antenna, or pick the kit apart for individual purchase.
Fits standard tachometer opening with a1.60″ mounting depth. Universal bracket provides multiple mounting options.
Great solution for skid steers and smaller equipment

Purchase the items as individuals

710617 Radio only $185.50

230073 Speakers $82.99

561086 Mounting bracket $45.00

210066 Antenna $26.99

FEATURES AW-30

● 12V/24V DC power (10V-30V)
● Weatherproof front panel & chassis
● Bluetooth for streaming audio (A2DP)
● Bluetooth for hands-free phone calls (HFP) via built-in microphone (remote-mount Bluetooth microphone sold separately)
● Caller ID phone numbers for incoming calls
● iPhone/Android charging via rear USB input-Type A (Front panel-mount USB input cable sold separately)
● USB input supports MP3/WMA playback
● Displays ID3 tag information
● 7-Channel NOAA weather band tuner
● AM/FM station presets (USA/Euro) with RDS
● 30 Programmable station presets (18 FM, 12 AM)
● 2-Channel amplified speaker output (25 watts x 2)
● Rear audio AUX input (RCA)
● Two-wire connection prevents battery drain
● Clock operates up to 30 days when vehicle battery is disconnected
● Station presets saved when vehicle battery is disconnected
● Built-in jobsite work timer
● Low battery alarm
● Corrosion- and UV-resistant materials and finishes
● Amber LED button backlighting and display
● Universal mounting provisions (AMPS Pattern)
● Regular/overhead mounting bracket and hardware included
● Operating temperature range: -22° F to 185 °F/-30° C to 85° C
● FCC certified
● Dimensions: 5.2” W x 3.4” H x 1.7” D
SAVE MONEY OVER THE JENSEN JHD922BT & JHD962BT. Same footprint and same connector as Jensen
SPECS

JHD962 BT
Features of JENSEN JHD962BT mobile audio system include:
• 50 watts max power (25W x 2); 20 watts RMS (10W x 2)
• Bluetooth® streaming audio (A2DP/AVRCP) and handsfree calling (HFP) - compatible with JMICHFP and JMICHFP2
microphones (sold separately) The JMICHFP2 requires cutting a hole to mount.
• Water and UV resistant front panel (IPX6)
• App control ready
• DAB+ (Digital Audio Broadcasting) Not used in the USA
• Weatherband
• AM/FM tuner with 30 presets
• RBDS (Radio Broadcast Data Service) with PTY search
• Rear USB port for device charging (1 amp output) Not for USB input.
• Stereo pre-amp line level output (2V RMS)
• Amplifier remote trigger (12VDC)
• Audio settings (volume/bass/treble/balance/fade)
• Toggle switch between day and night display
• Full dot matrix LCD
• 2-wire power with non-volatile memory and clock support
• Remote turn on
• Low battery alert
• Work timer
OWNERS MANUAL

JHD962BT COMBO
JHD962BT / REI 230073 / 210066 / JMICHFP
$420.99

REI 210066 Antenna
16" Flexible Mast - Universal Top or Side Mount with 60" Antenna Cable, Spring loaded

REI 230073 Speakers
• 5″W x 4″H x 3.5″D (excluding mount bracket)
• Polypropylene/mylar weatherproof speaker
• UV protected plastic enclosure
• 30 Watts max power
• 4 OHMS Impedance
• 4in 2-way coaxial speakers
• Max power handling 120 watts
• Cone material Injected Polypropylene
• Tweeter 1"
• Speakers can be mounted flush

SELECT TO VIEW MORE SURFACE MOUNT RADIOS

IF YOU ARE LOOKING FOR THE MOST ADVANCED SURFACE MOUNT STEREO COMBO !

COMBO Includes JMICHFP BT Mike

The JHD922BT and the JHD962BT have a bolt pattern on the back that works with our 2 pedestals. Allows a adjustable great way to mount either model securely to a surface. Available in a 4in or 6in model.
